Nest XPON 1GE ONT XP8100-HR

৳960

Key Features


XPON (GPON/EPON) Dual Mode Support

  • 1× Gigabit Ethernet (1GE) Port

  • Up to 20KM Fiber Transmission

  • Fast & Stable FTTH Connectivity

  • Low Power Consumption

  • Web UI & OMCI Management

  • Compatible with Major OLT Brands

  • Ideal for ISP & Home Broadband


  • Quantity:
    Brand: Nest

    Specification

    Item Parameters Specification
    Interface XPON Port 1 XPON (GPON/EPON) Port
    Downstream Speed 2.488Gbps
    Upstream Speed 1.244Gbps
    Optical SC/UPC Single mode fiber
    Distance Up to 20KM (1:128)
    Receiving Sensitivity ≤-30dBm
    Optical Power 0~+4dBm
    Ethernet Port 1GE RJ45 Auto MDI/MDI-X, 100m Transmission
    Management Standard OMCI (ITU-T G.984.4), Web Management
    Functions Status, Configuration, Alarm, Logs
    Physical Design Material Plastic Casing
    Power Input 12V DC
    Consumption <3W
    Dimension Size 115 x 133 x 25mm
    Weight 0.3kg
    Environment Operating Temp 0°C to 50°C
    Storage Temp -40°C to 85°C
    Humidity 10%–90% (Non-condensing)

    Product Details

    The Nest XPON 1GE ONT XP8100-HR is a high-speed GPON/EPON compatible Optical Network Terminal designed for FTTH networks. It features a 1*XPON port supporting 2.488Gbps downstream and 1.244Gbps upstream, ensuring stable and ultra-fast communication. With 1GE auto-negotiation port, web-based configuration, OMCI support, and low power consumption, this ONT provides superior performance and reliability for residential and enterprise connectivity. Its long-distance fiber support up to 20KM ensures coverage and efficiency, making it perfect for ISPs, SMEs, commercial networking, and broadband deployment.

    Warranty Policy

    This product comes with 1-Year Service Warranty, covering hardware malfunction and manufacturing defects. Physical damage, burn, or unauthorized modifications are not covered under warranty.
